MOSFET canal P

Name: LMT6L7P04
Brand: Shanghai Leiditech上海雷卯电子科技有限公司是专业的静电保护元件厂家,TVS二极管供应商;专业提供防雷防静电方案,电磁兼容EMC免费测试等服务,品质保证,库存充足,型号齐全,值得信赖,如有采购静电保护元件,TVS二极管需求,请联系雷卯,24小时服务热线:021-50828806.
SKU: 10115
Availability: InStock
Rating: 5 (1 reviews)

PAGE D'ACCUEIL > Tube d'application de champ MOSFET > MOSFET canal P

Caractéristiques /Applications Présentation de modèles similaires Rechercher des matériaux alternatifs

Caractéristiques /Applications

Description

The LMT6L7P04 uses advanced trench technology and

design to provide excellent Ros(on) with low gate charge .This

device is well suited for use as a load switch or in PWM

applications.

General Features

VDs =-40V,ID =-7A

RDs(ON) Typ 31mQ @ Vcs=-10V

RDs(ON) Typ 41mO @ VGs=-4.5V

High density cell design for ultra low Rdson

Fully characterized avalanche voltage and current

Excellent package for good heat dissipation

Application

Load switch

PWM application

Présentation de modèles similaires

LMTL7ND02 ， N ， Vdss= 20 V， ID（25℃）= 7 A， VGS= 10 V， VTH= 0.7 V， Ron(4.5V)Typ= 14 mΩ， Ron(4.5V)Max= 20 mΩ， SOT-23-6

LM6L4P02 ， P ， Vdss= -20 V， ID（25℃）= -4 A， VGS= 8 V， VTH= 0.6 V， Ron(4.5V)Typ= 37 mΩ， Ron(4.5V)Max= 50 mΩ， SOT-23-6

LM6L5P03 ， P ， Vdss= -30 V， ID（25℃）= -5.2 A， VGS= 20 V， VTH= -1.0..-3.0 V， Ron(10V)Typ= 41 mΩ， Ron(10V)Max= 55 mΩ， SOT-23-6

LMT6L7P04 ， P ， Vdss= -40 V， ID（25℃）= -7 A， VGS= 20 V， VTH= -1.6 V， Ron(10V)Typ= 28 mΩ， Ron(10V)Max= 35 mΩ， SOT-23-6

LMT6L5P06 ， P ， Vdss= -60 V， ID（25℃）= -5 A， VGS= 20 V， VTH= -1.65 V， Ron(10V)Typ= 60 mΩ， Ron(10V)Max= 75 mΩ， SOT-23-6

LM6604 ， N+P ， Vdss= 20/-20 V， ID（25℃）= 2.8/-2.8 A， VGS= 12 V， VTH= 0.75/-0.7 V， Ron(4.5V)Typ= 47/70 mΩ， Ron(4.5V)Max= 65/96 mΩ， SOT-23-6

LMSC05N02A ， N+P ， Vdss= 20/-20 V， ID（25℃）= 5.6/ -3.7 A， VGS= 10 V， VTH= 0.62/-0.62 V， Ron(4.5V)Typ= 19.5/49 mΩ， Ron(4.5V)Max= 25/64 mΩ， SOT-23-6

Rechercher des matériaux alternatifs

The brand LEIDITECH offers ESD part numbers such as ESD0521C, which can replace ST's ESDALC6V1-1BU2.

The brand LEIDITECH offers ESD part numbers such as ESD0521C, which can replace ST's ESDALC6V1-1U2.

The brand LEIDITECH offers ESD part numbers such as ESD9D5V, which can replace ST's ESDALC6V1-1M2.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1M3.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1P3.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1P5.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1P6.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1W5.

The brand LEIDITECH offers ESD part numbers such as SDA0505T6, which can replace ST's ESDA6V1-5P6.

The brand LEIDITECH offers ESD part numbers such as SDA05CW, which can replace ST's ESDA6V1-5W6.

The brand LEIDITECH offers ESD part numbers such as SDA05CW, which can replace ST's ESDALC6V1-5M6.

The brand LEIDITECH offers ESD part numbers such as SDA0505T6, which can replace ST's ESDALC6V1-5P6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA5V3SC5.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA5V3SC6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1M6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1P6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1SC5.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1SC6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1W5.

The brand LEIDITECH offers ESD part numbers such as SDA1511CDN, which can replace ST's ESDA14V2-1BF3.

The brand LEIDITECH offers ESD part numbers such as SDA2411CDN, which can replace ST's ESDALC20-1BF4. The brand LEIDITECH of offers the ESD part number SM05, which can replace the ST's ESDAVLC6V1-1BT2.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC4-1BF3.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC6-1BT2.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC6-1BT2Y.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC6-1MY2.

The brand LEIDITECH of offers the ESD part number ULC0721C, which can replace the ST's ESDARF02-1BU2.

The brand LEIDITECH of offers the ESD part number ULC0721C, which can replace the ST's ESDARF02-1BU2CK.

The brand LEIDITECH of offers the ESD part number SAT100H200T, which can replace the ST's STPS40170C.

The brand LEIDITECH of offers the ESD part number SAT60TL45CPT, which can replace the ST's STPS60L30CW.

The brand LEIDITECH of offers the ESD part number SLT40L60FCT, which can replace the ST's STPS30L60CT.
